Integral Memory is a UK based company that has a long history selling RAM and flash memory. Integral's top performing Secure Digital card is the UltimaPro X2 UHS-II V90. It boasts 280 MB/s read and 240 MB/s write speed maximums. The UltimaPro X2 UHS-II V90 SDXC card is covered in this review. According to the company the card uses Pseudo SLC (pSLC) capable of 20,000 Read/Write cycles. The card also carries the Video Speed Class 90 (V90) label, meaning it meets the standard set by the SD Association to provide at least 90MB/s continuous write speed for recording 8K and 4K video.
Integral UltimaPro X2 280/240 MB/s cards are produced in 32, 64 and 128 GB capacities. The 64GB version (INSDX64G-280/240U2) with UPC 5055288436183 was tested for this review. The card has a 5-year warranty.
To test the Integral UltimaPro X2 card, a variety of SD card readers were employed. In benchmark testing the 64GB card attained a 299 MB/s sequential read speed. This was above the 280 MB/s read speed rating. Write speed reached 263.9 MB/s sequential, which is also beyond Integral's 240 MB/s write speed claim. Overall the card achieved its claimed performance and worked well in a variety of card readers. The only exception was the Verbatim USB-C reader, which failed to work with the card. The Verbatim reader had issues with several other UHS-II cards.
In UHS-I devices the UltimaPro X2 will revert to UHS-I mode. In such a situation the read speed measured up to 96.7 MB/s, while write speed reached 92.5 MB/s.
Card: Integral UltimaPro X2 UHS-II V90 64GB
Benchmark: CrystalDiskMark 3.0.3 x64
Program settings: 1000 MB, 5 passes, random test data
Operating system: Windows 10 Pro
Motherboard: Gigabyte GA-Z77X-UD3H
Processor: Intel Core i7-3770K @ 4.40GHz
RAM: 32GB DDR3 1600
Integral UltimaPro X2 UHS-II V90 64GB Card Reader Benchmarks | Seq. Read 1000MB MB/s | Seq. Write 1000MB MB/s | Rand. Read 512KB MB/s | Rand. Write 512KB MB/s | Rand. Read 4KB MB/s QD1 | Rand. Read 4KB IOPS QD1 | Rand. Write 4KB MB/s QD1 | Rand. Write 4KB IOPS QD1 | Rand. Read 4KB MB/s QD32 | Rand. Read 4KB IOPS QD32 | Rand. Write 4KB MB/s QD32 | Rand. Write 4KB IOPS QD32 |
---|---|---|---|---|---|---|---|---|---|---|---|---|
Delkin Black Rugged Card Reader | 298.995 | 263.925 | 212.891 | 2.819 | 9.071 | 2214.5 | 2.077 | 507.1 | 12.324 | 3008.8 | 1.860 | 454.1 |
SanDisk Extreme Pro SD UHS-II Reader/Writer | 277.364 | 244.909 | 203.590 | 2.894 | 9.822 | 2398.0 | 2.146 | 523.9 | 13.119 | 3203.0 | 1.808 | 441.5 |
SanDisk Extreme Pro SD UHS-II USB-C Reader | 273.601 | 249.750 | 197.648 | 2.804 | 12.726 | 3107.1 | 2.323 | 567.0 | 14.519 | 3544.6 | 1.990 | 486.0 |
SanDisk ImageMate Pro Multi-Card Reader/Writer | 273.067 | 243.883 | 199.811 | 3.012 | 9.275 | 2264.4 | 2.344 | 572.4 | 11.891 | 2903.1 | 1.848 | 451.1 |
Sony S1 High Speed UHS-II Reader/Writer | 272.960 | 241.302 | 201.178 | 2.666 | 9.690 | 2365.8 | 2.144 | 523.5 | 12.933 | 3157.5 | 1.880 | 459.0 |
SanDisk Extreme Pro UHS-II USB-C Reader SDDR-409 | 272.534 | 248.448 | 197.714 | 2.740 | 12.070 | 2946.7 | 2.262 | 552.2 | 14.378 | 3510.2 | 1.874 | 457.6 |
Lexar LRWM04U-7000 UHS-II Reader | 268.969 | 237.718 | 202.488 | 2.876 | 11.305 | 2760.0 | 2.286 | 558.0 | 14.745 | 3599.9 | 2.084 | 508.8 |
Lexar Professional Workflow SR2 UHS-II | 268.866 | 237.530 | 201.750 | 2.880 | 11.352 | 2771.5 | 2.204 | 538.0 | 14.559 | 3554.5 | 2.001 | 488.6 |
Hama USB Type-C 3.1 UHS-II SD Card Reader | 263.992 | 236.940 | 196.077 | 2.806 | 12.454 | 3040.5 | 2.168 | 529.4 | 16.605 | 4054.1 | 2.006 | 489.7 |
Hama USB 3.0 UHS-II SD Card Reader | 258.780 | 229.724 | 200.743 | 3.185 | 12.353 | 3015.9 | 2.232 | 544.8 | 15.360 | 3749.9 | 1.882 | 459.4 |
Kingston FCR-HS4 Card Reader | 243.883 | 220.243 | 179.199 | 2.813 | 11.367 | 2775.0 | 2.364 | 577.1 | 15.336 | 3744.2 | 2.256 | 550.7 |
ProMaster Professional Dual Card Reader SD UHS-II | 243.713 | 220.706 | 179.706 | 2.735 | 11.154 | 2723.1 | 2.140 | 522.6 | 15.413 | 3763.0 | 2.262 | 552.3 |
Delkin Dual Slot SD UHS-II and CF Card Reader | 243.713 | 220.590 | 179.766 | 2.746 | 10.914 | 2664.5 | 2.373 | 579.4 | 15.316 | 3739.3 | 2.123 | 518.3 |
Transcend Multi-Card Reader RDF9 | 243.657 | 220.521 | 179.796 | 2.880 | 11.482 | 2803.3 | 2.267 | 553.4 | 15.316 | 3739.3 | 2.215 | 540.9 |
Delkin Multi-Card CFast SD UHS-II microSD Reader | 243.515 | 220.266 | 178.784 | 2.805 | 11.077 | 2704.2 | 2.228 | 544.0 | 15.411 | 3762.4 | 2.227 | 543.6 |
Lexar Professional Dual Slot UHS-II Card Reader | 243.317 | 220.683 | 179.497 | 2.941 | 11.475 | 2801.4 | 2.240 | 546.9 | 15.278 | 3729.9 | 2.151 | 525.0 |
Kingston MobileLite G4 UHS-II | 238.286 | 216.090 | 176.668 | 2.995 | 11.269 | 2751.3 | 2.189 | 534.5 | 15.298 | 3734.9 | 2.304 | 562.6 |
SanDisk Extreme Pro UHS-II SD Reader/Writer | 237.853 | 216.313 | 177.077 | 2.880 | 11.408 | 2785.1 | 2.110 | 515.0 | 15.353 | 3748.4 | 2.179 | 532.0 |
Sony MRW-E90 XQD 2.0 / SD UHS-II Card Reader | 236.886 | 213.494 | 187.774 | 2.682 | 9.660 | 2358.4 | 2.250 | 549.3 | 13.966 | 3409.7 | 2.109 | 514.8 |
DriverGenius USB 3.1(G1) / 3.0 UHS-II SD Card Reader | 236.405 | 214.039 | 185.912 | 3.083 | 10.136 | 2474.6 | 2.170 | 529.9 | 13.830 | 3376.5 | 2.099 | 512.4 |
Delkin Travel Reader | 96.670 | 91.659 | 86.189 | 1.963 | 8.792 | 2146.4 | 0.161 | 39.2 | 10.900 | 2661.1 | 0.137 | 33.6 |
Delkin Universal Memory Card Reader | 95.795 | 82.280 | 87.697 | 2.207 | 8.009 | 1955.4 | 0.123 | 30.1 | 10.482 | 2559.1 | 0.130 | 31.8 |
Transcend Multi-Card Reader RDF8 Black | 95.760 | 92.549 | 87.769 | 2.068 | 7.958 | 1942.8 | 0.153 | 37.3 | 10.564 | 2579.1 | 0.134 | 32.8 |
Transcend SD Card Reader RDF5 Black | 94.902 | 91.022 | 86.104 | 1.964 | 6.619 | 1615.9 | 0.139 | 34.0 | 7.208 | 1759.9 | 0.124 | 30.3 |
Verbatim USB-C Pocket Card Reader | 0.000 | 0.000 | 0.000 | 0.000 | 0.000 | 0.0 | 0.000 | 0.0 | 0.000 | 0.0 | 0.000 | 0.0 |
The Integral card will be included in upcoming camera tests. Write speed results obtained in cameras will be added to the table below.
Integral UltimaPro X2 UHS-II V90 64GB Tested in Camera | Write Speed (MB/s) |
---|---|
Canon EOS R | 177.1 |
Fuji X-T3 | 158.6 |
Nikon Coolpix P1000 | 33.6 |
Cameras tested with this card: Canon EOS R, Fuji X-T3, Nikon Coolpix P1000
The following table contains information encoded in the SD card.
Integral UltimaPro X2 UHS-II V90 64GB SD — Internal Card Information | |
---|---|
Serial number (PSN) | 3668080956 |
Product Name (PNM) | SD64G |
Product Revision | 5.0 |
Manufacturer ID (MID) | 0x000027 |
OEM ID (OID) | PH |
Manufacture Date (MDT) | 07/2018 |
Total capacity | 64,172,851,200 bytes |
The internal SD cards register shows that this Integral card was produced in July 2018. Its OEM ID indicates that the card has a Phison controller.
